Residential Elevators
Once considered a luxury, residential elevators are now in common use in both existing and newly constructed homes. Safe, reliable, stylish and easy to use, residential elevators can greatly enhance the livability of all levels of your home now and in the future.
Roped Hydraulic Elevators
- 1:2 cable/roped hydraulic unit utilizing (2) 3/8” x 7 x 19 steel core aircraft wire rope integrated into a rams header sheave mounted to a 80 mm diameter hydraulic cylinder
- 950 lbs capacity up to 44'; (750 lbs opt.)
- 2 speed valve
- Remote machine room up to 40’
- Submerged motor for quiet operation
- Floor specific battery descent
- 40 fpm travel speed
Winding Drum Elevators
- Inverter controlled winding drum unit utilizing (2) 3/8” x 7 x 19 steel core aircraft wire rope
- 950 lbs capacity, (750 lbs opt.)
- A variety of drum configurations available
- Variable speed for a quality ride
- Quiet operation
- No oil usage/reduced maintenance
- Floor specific battery descent (opt.)
- 40 fpm travel speed
- Features
- Many sizes available as a standard feature
- Cable and Hydraulic designs available
- Can be customized with many finishes available
- Benefits
- Comfortable access to all levels of your home
- Age in place - no need to move in the future
- Add uniqueness and value to your home
- Good return on access solution investment
